无线模组
杰出的射频机能、、、高集成度和安全保险
银河yh0076创新推出的Wi-Fi模组系列，，，基于高机能GD32VW553芯片，，，专为物联网（IoT）利用设计。�！！！８媚Ｗ檠∪ISC-V内核，，，主频高达160MHz，，，集成了2.4GHz Wi-Fi 6和Bluetooth LE 5.2射频�？椋�，，具备卓越的基带与射频机能，，，可满足实时处置和高效通讯需要。�！！！Ｆ淠诓考筛叽�4MB Flash和320KB SRAM，，，并提供丰硕的通用有线接口，，，全面提升设备开发的矫捷性。�！！！Ｍ保�，，该无线模组具备多重安全个性，，，简化了高机能无线设备的安全衔接与治理，，，支持切合CSA衔接尺度联盟Matter over Wi-Fi利用尺度，，，助力开发越发智能、、、靠得住的物联网解决规划。�！！！Ｒ觵h0076创新凭借多元化的产品组合和自主研发的软件技术，，，致力于为各类物联网场景提供全面支持，，，加快无线模组在智能家居、、、工业节制、、、智慧城市等领域的落地利用。�！！！�
显示12种器件
清空
清空
| 型号 | Product | IEEE 802.11 | Bluetooth | Core | Max Speed (MHz) | Flash (Bytes) | SRAM (Bytes) | I/O | Antenna Type | Module Size(mm) | Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|
| GD32VW553-UNIFI-IMH6 | GD32VW553-UNIFI | (b/g/n/ax) HT20 | BLE 5.2 | RISC-V | 160 | 4096K | 320K | up to 18 | Onboard | 24 x 16 x 2.2 | -40 ~ 85℃ |
| GD32VW553-UNIFI-IMH7 | GD32VW553-UNIFI | (b/g/n/ax) HT20 | BLE 5.2 | RISC-V | 160 | 4096K | 320K | up to 18 | Onboard | 24 x 16 x 2.2 | -40 ~ 105℃ |
| GD32VW553-UNIFI-EMH6 | GD32VW553-UNIFI | (b/g/n/ax) HT20 | BLE 5.2 | RISC-V | 160 | 4096K | 320K | up to 18 | External | 24 x 16 x 2.2 | -40 ~ 85℃ |
| GD32VW553-UNIFI-EMH7 | GD32VW553-UNIFI | (b/g/n/ax) HT20 | BLE 5.2 | RISC-V | 160 | 4096K | 320K | up to 18 | External | 24 x 16 x 2.2 | -40 ~ 105℃ |
| GD32VW553-MD1-IMH6 | GD32VW553-MD1 | (b/g/n/ax) HT20 | BLE 5.2 | RISC-V | 160 | 4096K | 320K | up to 28 | Onboard | 20 x 18 x 2.4 | -40 ~ 85℃ |
| GD32VW553-MD1-IMH7 | GD32VW553-MD1 | (b/g/n/ax) HT20 | BLE 5.2 | RISC-V | 160 | 4096K | 320K | up to 28 | Onboard | 20 x 18 x 2.4 | -40 ~ 105℃ |
| GD32VW553-MD1-EMH6 | GD32VW553-MD1 | (b/g/n/ax) HT20 | BLE 5.2 | RISC-V | 160 | 4096K | 320K | up to 28 | External | 20 x 18 x 2.4 | -40 ~ 85℃ |
| GD32VW553-MD1-EMH7 | GD32VW553-MD1 | (b/g/n/ax) HT20 | BLE 5.2 | RISC-V | 160 | 4096K | 320K | up to 28 | External | 20 x 18 x 2.4 | -40 ~ 105℃ |
| GD32VW553-MINI-IMK6 | GD32VW553-MINI | (b/g/n/ax) HT20 | BLE 5.2 | RISC-V | 160 | 4096K | 320K | up to 20 | Onboard | 15 x 12.4 x 2.4 | -40 ~ 85℃ |
| GD32VW553-MINI-IMK7 | GD32VW553-MINI | (b/g/n/ax) HT20 | BLE 5.2 | RISC-V | 160 | 4096K | 320K | up to 20 | Onboard | 15 x 12.4 x 2.4 | -40 ~ 105℃ |
| GD32VW553-MINI-EMK6 | GD32VW553-MINI | (b/g/n/ax) HT20 | BLE 5.2 | RISC-V | 160 | 4096K | 320K | up to 20 | External | 9.5 x 12.4 x 2.4 | -40 ~ 85℃ |
| GD32VW553-MINI-EMK7 | GD32VW553-MINI | (b/g/n/ax) HT20 | BLE 5.2 | RISC-V | 160 | 4096K | 320K | up to 20 | External | 9.5 x 12.4 x 2.4 | -40 ~ 105℃ |
